Super Strong Ferrite Magnet SrO Fe2O3 Motor Ceramic Processing

Ask Lasest Price
Payment Terms :	L/C, T/T
Brand Name :	JOINT-MAG
Model Number :	OEM
Price :	Negotiable
Supply Ability :	5000T Annual Capacity
Certification :	IATF 16949

Add to Cart

Product Details
Company Profile

Super Strong Ferrite Magnet SrO Fe2O3 Motor Ceramic Processing

Super Strong Permanent Magnet-1

Ferrite magnet is made from SrO and Fe2O3 as main material by ceramic processing technology. The products appears in rings,disks,blocks.segments,etc.It’s mainly used in various motors,especially the car motors,start-up motors for motorcycles, home fitness equipment’s and electric toys as well. The arc magnet main used in motor, the ring/round magnet mostly used in speaker. And disk/disc are often applied to horn or packaging. The block magnet is used in motor or packaging as a absorption.

Prouct Name	Super Strong Permanent Magnet
Brand Name	Joint-Mag
Type	Starter Parts
Composite	Ferrite Magnet
Shape	Magnet Tile, Arc, Segment, Block, Sheet, other according to your requirements
Application	Industrial Magnet
Size	According to customer's requirements
Car Make	Automobile Staters
Color	Charcoal gray
Place of Origin	Sichuan, China (Mainland)

GRADE	Br		Hcb		Hcj		(BH)max
GRADE	T	GS	KA/m	OE	KA/m	OE	KJ/m3	MGOe
JC-Y3932	0.375-0.400	3750-4000	230-275	2890-3456	235-290	2950-3645	26.5-31.5	3.33-3.96
JC-Y3939	0.380-0.400	3800-4000	255-290	3200-3645	260-325	3260-4080	26.5-31.8	3.33-4.00
JC-Y4041	0.390-0.415	3900-4150	260-300	3260-3770	300-350	3770-4400	27.0-32.0	3.39-4.02
JC-Y4127	0.400-0.420	4000-4200	180-225	2260-2825	185-228	2320-2865	30.0-33.6	3.77-4.22
JC-Y4231	0.410-0.430	4100-4300	220-260	2765-3265	255-270	2825-3390	31.5-35.5	3.95-4.46
JC-Y3849	0.370-0.400	3700-4000	271-305	3405-3830	370-400	4650-5025	26.0-31.2	3.27-3.92
JC-Y4240	0.410-0.430	4100-4300	285-314	3580-3945	306-340	3845-4270	31.5-34.4	3.95-4.32
JC-Y4545	0.440-0.460	4400-4600	310-354	3895-4445	346-375	4350-4710	36.5-39.5	4.59-4.96
JC-Y4350	0.420-0.440	4200-4400	295-325	3700-4080	382-410	4800-5150	33.5-36.5	4.21-4.59

Specifications

1. Permanent Ferrite Magnet
2. JC-Y4350, FB5H...
3. Annual Capacity: 5000/T.
4, Excellent service

5. Strong SrO·6Fe2O3 Magnet with high quality
6. Custom-made dimension
7. Reasonable price
8. Certificate: ISO9001: 2000

Ferrite Magnets' outstanding properties

Br can reach 4300 GS Hcb can reach 3946 OE,

Hcj can reach 4147 OE (BH)max can reach 4.45 MG OE.

Super Strong Ferrite Magnet SrO Fe2O3 Motor Ceramic Processing

Advantages

Pretty strong hold between two of these blocks even if a couple of them by contacting the other one or plain iron. It's difficult to pull away them(easy to slide however).

Ferrite Magnet applications:

Applicable for the starters of 1.0W, 1.2W. 1.4W, 1.5W, 1.7W are available and mainly applied in Nissan and Red Flag based on JC-Y3744, JU-Y3849 MATERIAL Grade and different requirements of environmental temperatures can be adapted to.

Packaging & Delivery

Packaging Details

Carton: Wood Pallet
Special Package according to your requirementsDelivery Time10-40 days or according to the order
